Teflon PTFE Heat Shrinkable Tube
Nov 15, 2017
Leave a message
Basic Info
Material: PTFE
Customized: Customized
Shrink Temperature: 150 Centigrade~175 Centigrade
Type: Heat-shrink Tube
Certification: SGS
Condition: Used
Item: Teflon Ptee Heat Shrink Tube
Shrink Ratio: 1.7:1 4:1
Specification: ROHS
Description:
A highly flame retardant heat shrinkable tubing manufactured from modified PTFE Provides insulation and mechanical protection in severe chemical and thermal environments Thin wall, high shrink ratio, flexible and transparent Major uses: electrical insulation, protection of electronic components, covering of hydraulic hose and couplings, prevention against contamination and corrosion High mechanical strength and extremely low coefficient of friction make it ideal for reducing damage to bearing shafts etc.
Features
2Continuous operating temperature: -65°C~260°C
2Resistant to corrosion, strong acid, strong base, chemical reagents, and oil etc
2Excellent Dielectric Insulation Properties
2Excellent electrical performance that does not change with the temperature and frequency
2Excellent mechanical performance, shock proof, high elasticity
2Ultra low friction coefficient, highly flame retardant
2Flammability: VW-1
2Shrink Ratio: 1.7:1, 4:1
2Standard color: clear/transparent
Technical Performance
| Property | standard |
| Tensile strength | ≥25MPa |
| elongation at break | ≥300% |
| Flammability | VW-1 |
| dielectric strength | ≥26kV/mm |
| volume resistivity | ≥1014Ω.cm |
| copper corrosion | Pass |
| water absorption | <0.1% |
Dimensions(1.7:1)
| Size | As supplied D(mm) | After full recovered(mm) | Standard Package (M/roll, M/pcs) | |
| Diameter d | Wall thickness w | |||
| Φ1.0 | 1.0±0.2 | ≤0.5 | 0.20±0.05 | 200 |
| Φ1.5 | 1.5±0.2 | ≤0.9 | 0.20±0.05 | 200 |
| Φ2.0 | 2.0±0.2 | ≤1.3 | 0.20±0.05 | 200 |
| Φ2.5 | 2.5±0.2 | ≤1.5 | 0.20±0.05 | 200 |
| Φ3.0 | 3.0±0.2 | ≤1.8 | 0.20±0.05 | 200 |
| Φ3.5 | 3.5±0.2 | ≤2.0 | 0.25±0.05 | 100 |
| Φ4.0 | 4.0±0.3 | ≤2.5 | 0.25±0.05 | 100 |
| Φ4.5 | 4.5±0.3 | ≤2.8 | 0.25±0.05 | 100 |
| Φ5.0 | 5.0±0.3 | ≤3.0 | 0.25±0.05 | 100 |
| Φ6.0 | 6.0±0.3 | ≤3.8 | 0.25±0.05 | 100 |
| Φ7.0 | 7.0±0.3 | ≤4.0 | 0.25±0.05 | 100 |
| Φ8.0 | 8.0±0.3 | ≤4.8 | 0.25±0.05 | 1.0 |
| Φ9.0 | 9.0±0.3 | ≤5.0 | 0.30±0.05 | 1.0 |
| Φ10.0 | 10.0±0.3 | ≤5.8 | 0.30±0.05 | 1.0 |
| Φ11.0 | 11.0±0.3 | ≤6.4 | 0.30±0.05 | 1.0 |
| Φ12.0 | 12.0±0.3 | ≤7.0 | 0.30±0.05 | 1.0 |
| Φ13.0 | 13.0±0.3 | ≤7.5 | 0.35±0.05 | 1.0 |
| Φ14.0 | 14.0±0.3 | ≤8.0 | 0.35±0.05 | 1.0 |
Dimension(4:1)
| Size | As supplied D(mm) | After full recovered(mm) | Standard package (M/Roll, M/Pcs) | |
| ID d | wall thickness w | |||
| Φ2.0 | ≥2.0 | ≤0.46 | 0.25±0.05 | 200 |
| Φ2.5 | ≥2.5 | ≤0.50 | 0.25±0.05 | 200 |
| Φ3.0 | ≥3.0 | ≤0.66 | 0.25±0.05 | 200 |
| Φ3.5 | ≥3.5 | ≤0.68 | 0.30±0.05 | 100 |
| Φ4.0 | ≥4.0 | ≤0.81 | 0.35±0.05 | 100 |
| Φ4.5 | ≥4.5 | ≤0.98 | 0.40±0.05 | 100 |
| Φ5.0 | ≥5.0 | ≤1.23 | 0.40±0.05 | 100 |
Non-standard dimensions, larger or smaller, please contact us.
