High Temperature Teflon Shrinkable Tubes Hose

High Temperature Teflon Shrinkable Tubes Hose

This product is highly electrical insulating, highly flame retardant,self-lubricating and highly resistant to super high temperature

Send InquiryChat Now
Product Details

High Temperature Teflon Shrinkable Tubes Hose


Introduction

PTFE Teflon Hose, short for polyethylene tubing, is made of polyethylene resin through special extrusion and ring process.This product is highly electrical insulating, highly flame retardant,self-lubricating and highly resistant to super high temperature, chemical reagents and almost all oil and other chemicals.

Features

1:Chemically inert, resistant to almost all chemicals

2:Low surface friction coefficient, high bond resistance

3:Good electrical characteristics


Advantages:

1.Resistance strong acid and alkali.

2.Resistance aging can be used outdoor for a long time





Technical parameter

Product TypeHeat shrink tube
MaterialTeflon
Flame retardantVW-1
Operation Temperature-70℃-200℃
Withstand Voltage600V
LengthCustomized
Shrink ratio4:1
Working pressure(at room temperature)10-15KG
Breakdown strength5KV/mm
UsageMedical equipment,Household appliance,Motors
Place of OriginGuangdong, China (Mainland)



Detailed Images



Teflon Heat Shrink Tubing Specification
Standard Specific(mm)Inner Diameters Before   Shrink(mm)Average Thickness(mm)Inner Diameters After      Shrink(mm)
Φ0.5±0.20.10±0.05≤0.4
Φ0.8±0.20.10±0.05≤0.47
Φ1.0±0.20.10±0.05≤0.66
Φ2.0±0.20.10±0.05≤0.97
Φ2.5±0.20.10±0.05≤1.32
Φ3.0±0.20.13±0.05≤1.65
Φ3.5±0.20.13±0.05≤1.83
Φ4.0±0.30.13±0.05≤2.57
Φ4.5±0.30.13±0.05≤3.1
Φ5.0±0.30.13±0.05≤3.4
Φ6.0±0.30.13±0.05≤3.8
Φ6.5±0.30.13±0.05≤4.1
Φ7.0±0.30.13±0.05≤4.2
Φ7.5±0.30.18±0.05≤4.5
Φ8.0±0.30.18±0.05≤4.8
Φ8.5±0.30.18±0.05≤5.2
Φ9.0±0.30.18±0.05≤5.3
Φ9.5±0.30.18±0.05≤5.6
Φ10.0±0.30.18±0.05≤6.2
Φ10.5±0.30.18±0.05≤6.2
Φ12±0.30.18±0.05≤6.95

If you need customized / special sizes, please click here to send an inquire to us. We will respond you in 24 hours.
