Silicone High Temperature Shrinkable Tubes
Our materials range from the heat shrinkable(single wall, dual wall, medium wall and heavy duty), silicone heat shrink hose
Send Inquiry
Description
Technical Parameters
Guanghai Electronic, founded in 2009, is one of the leading Silicone High Temperature Shrinkable Tubes manufacturers and suppliers in China, offering you the customized service and the free sample for checking. Through special extrusion, this products made in China must be your best choice.
Technical parameter
| Product Type | Heat shrink tube |
| Material | Silicone rubber |
| Flame retardant | VW-1 |
| Operation Temperature | -60℃-200℃ |
| Withstand Voltage | 600V |
| Length | Customized |
| Shrink ratio | 2:1 |
| Working pressure | 2-2.5pa |
| Shrinking temperature | 80-125℃ |
| Usage | Medical equipment,Household appliance,Motors |
| Place of Origin | Guangdong, China (Mainland) |
Detailed Images
| Silicone Heat Shrink Tube Specification | ||||
| Specific | Before Shrink Inner Diameters(mm) | Thickness(mm) | After Shrink Inner Diameters(mm) | Wall Thickness(mm) |
| Φ0.8 | ≥0.8 | 0.5±0.1 | 0.5 | 0.7±0.1 |
| Φ1.0/1.2 | ≥1 | 0.5±0.1 | 0.6 | 0.7±0.1 |
| Φ1.5/1.7 | ≥1.5 | 0.5±0.1 | 0.8 | 0.7±0.1 |
| Φ2.0 | ≥2 | 0.5±0.1 | 1.2 | 0.7±0.1 |
| Φ2.5 | ≥2.5 | 0.5±0.1 | 1.5 | 0.7±0.1 |
| Φ3.0 | ≥3 | 0.5±0.1 | 1.8 | 0.7±0.1 |
| Φ3.5 | ≥3.5 | 0.5±0.1 | 2 | 0.7±0.1 |
| Φ4.0 | ≥4 | 0.5±0.1 | 2.5 | 0.7±0.1 |
| Φ4.5 | ≥4.5 | 0.5±0.1 | 2.8 | 0.7±0.1 |
| Φ5.0 | ≥5 | 0.5±0.1 | 3 | 0.7±0.1 |
| Φ6.0 | ≥6 | 0.5±0.1 | 3.8 | 0.7±0.1 |
| Φ7.0 | ≥7 | 0.5±0.1 | 4 | 0.7±0.1 |
| Φ8.0 | ≥8 | 0.5±0.1 | 4.8 | 0.7±0.1 |
| Φ9.0 | ≥9 | 0.5±0.1 | 5 | 0.7±0.1 |
| Φ10.0 | ≥10 | 0.8±0.1 | 6.5 | 1.7±0.1 |
| Φ11 | ≥11 | 1.0±0.1 | 7 | 1.7±0.1 |
| Φ12 | ≥12 | 1.0±0.1 | 7.5 | 1.7±0.1 |
| Φ15 | ≥15 | 1.0±0.1 | 9.5 | 1.7±0.1 |
| Φ16 | ≥16 | 1.0±0.1 | 10 | 1.7±0.1 |
| Φ18 | ≥18 | 1.0±0.1 | 11 | 1.7±0.1 |
| Φ20 | ≥20 | 1.0±0.1 | 13 | 1.7±0.1 |
| Φ25 | ≥25 | 1.0±0.1 | 15 | 1.7±0.1 |
| Φ30 | ≥30 | 1.0±0.1 | 20 | 1.7±0.1 |
| Φ35 | ≥35 | 1.0±0.1 | 24 | 1.7±0.1 |
| Φ40 | ≥40 | 1.0±0.1 | 27 | 1.7±0.1 |
| Φ50 | ≥48 | 1.0±0.1 | 34 | 1.7±0.1 |
| Φ60 | ≥58 | 1.5±0.2 | 38 | 2.5±0.2 |
| Φ70 | ≥68 | 1.5±0.2 | 47 | 2.5±0.2 |
| Φ80 | ≥78 | 1.5±0.2 | 54 | 2.5±0.2 |
| Φ90 | ≥88 | 1.5±0.2 | 60 | 2.5±0.2 |
| Φ100 | ≥98 | 1.5±0.2 | 67 | 2.5±0.2 |
| Φ110 | ≥108 | 1.5±0.2 | 74 | 2.5±0.2 |
Silicone heat shrink tube is not only with the performance of general silicone tube, High temperature resistance,high pressure resistance,soft and elastic, But also with thermal shrinkage performance.
Features
1.Acid and alkali resistant, corona resistant, prevent mildew
2.Flame retardant, flexible
Advantage
1.Outstanding flexibility;
2.High adhesion,Eco-friendly
If you need customized / special sizes, please click here to send an inquire to us. We will respond you in 24 hours.
