Blank PVC Heat Shrink Tubing For 18650 Battery

Name: Blank PVC Heat Shrink Tubing For 18650 Battery Manufacturers and Suppliers China - Customized Products Factory - Guanghai Electronic
Brand: Guanghai
SKU: 28572527

Colorful PVC Heat Shrink Film Sleeve Wrap for Battery Cable Technical Parameters Introduction: PVC heat shrink tubing is widely used in electronic capacitors,inductors ,all kinds of lithium battery core ,the combination of packaging,the mop bar ,tool rods ,garden tools,braces and other tubular...

Send Inquiry

Description

Technical Parameters

Guanghai Electronic, founded in 2009, is one of the leading Blank PVC Heat Shrink Tubing For 18650 Battery manufacturers and suppliers in China, offering you the customized service and the free sample for checking. Through special extrusion, this products made in China must be your best choice.

Blank PVC Heat Shrink Tubing For 18650 Battery

Technical Parameters

Product Type	Heat shrink tube
Material	PVC
Flame retardant	VW-1
Operation Temperature	-55℃-105℃
Withstand Voltage	600V
Length	Customized
Shrink ratio	3:1
Water absorption	<0.2%
Shrinking temperature	50℃
Usage	Battery,Cable

PVC heat shrink tubing is widely used in electronic capacitors,inductors ,all kinds of lithium battery core ,the combination of packaging,the mop bar ,tool rods ,garden tools,braces and other tubular itmes covered .And can be used for low-voltage indoor connector ,wiring harness logo , insulated skin coating .

Detailed Images

PVC Heat Shrink Tube Specification Table
Specification	Flat Width(mm)	Thickness(mm)	Packages
Specification	Flat Width(mm)	Thickness(mm)	Packages
3	5.5±0.2	0.085±0.01	200Meter/Roll
4	7.3±0.2	0.09±0.01	200Meter/Roll
5	9.2±0.2	0.09±0.01	200Meter/Roll
6	10.6±0.2	0.09±0.01	200Meter/Roll
6.3	11.1±0.2	0.09±0.01	200Meter/Roll
8	14.1±0.2	0.095±0.01	200Meter/Roll
9	15.5±0.2	0.095±0.01	200Meter/Roll
10	17.1±0.2	0.1±0.01	200Meter/Roll
11	18.7±0.2	0.1±0.01	200Meter/Roll
12	20.7±0.2	0.1±0.015	200Meter/Roll
12.5	21.6±0.2	0.1±0.015	200Meter/Roll
13	22.1±0.2	0.1±0.015	200Meter/Roll
14.5	24.6±0.3	0.1±0.015	200Meter/Roll
16	27.1±0.3	0.11±0.015	200Meter/Roll
18	30.1±0.3	0.11±0.015	200Meter/Roll
20	33.2±0.3	0.12±0.015	200Meter/Roll
22	36.2±0.3	0.12±0.015	200Meter/Roll
25	41.4±0.4	0.14±0.02	200Meter/Roll
30	50.0±0.6	0.14±0.02	200Meter/Roll
35	57.0±0.7	0.14±0.02	200Meter/Roll
40	66.2±1	0.14±0.02	200Meter/Roll
50	83.5±1.5	0.2±0.023	200Meter/Roll
63.5	106.0±1.5	0.2±0.023	100Meter/Roll

If you need customized / special sizes, please click here to send an inquire to us. We will respond you in 24 hours. 图片129.jpg
