Food Grade Flexible Hose Silicone Braided Rubber Tubing

Guanghai Electronic, founded in 2009, is one of the leading food grade flexible hose silicone braided rubber tubing manufacturers and suppliers in China, offering you the customized service and the free sample for checking. Through special extrusion, this products made in China must be your best choice.



Food Grade Flexible Hose Silicone Braided Rubber Tubing

Product Type	Silicone Reinforce Braided Tube
Material	Silicone
Certifications	ROHS,SGS,FDA,REACH
Operation Temperature	-60℃-220℃
Thinkness Range	1mm-4mm or OEM
Specification	Customized
BPA Free	Yes
Working pressure(at room temperature)	2~2.5Pa
Feature	Better Tolerence, Durable, Thermostability, FDA, etc
Usage	Mainly apply in liquid transport
Place of Origin	Guangdong, China (Mainland)

Features:

1.FDA silicon rubber hoses Temperature range:-60℃ +220℃

2.It has been specially  processed, no toxic and no smell, flaming resistance, good heatproof,aging resistance

3.It is slick surface, soft and flexible

4.It's FDA and also applied in the liquid transport and some siege weapons.

Detailed Images

Specification Size of Silicone hoses

Number	Inner Diameters		Thickness		Outer Diameter		Working Pressure
GH-001	0.053inch	1.590mm	0.105inch	2.67mm	0.282inch	7.16mm	200PSI	13.79BAR
GH-002	0.125inch	3.180mm	0.120inch	3.05mm	0.375inch	9.53mm	175PSI	12.07BAR
GH-003	0.188inch	4.760mm	0.130inch	3.30mm	0.462inch	11.73mm	170PSI	11.72BAR
GH-004	0.250inch	6.350mm	0.125inch	3.17mm	0.500inch	12.70mm	140PSI	9.65BAR
GH-005	0.375inch	9.530mm	0.125inch	3.17mm	0.625inch	15.88mm	140PSI	9.65BAR
GH-006	0.500inch	12.70mm	0.187inch	4.75mm	0.875inch	22.22mm	105PSI	7.24BAR
GH-007	0.625inch	15.88mm	0.170inch	4.32mm	0.990inch	25.15mm	100PSI	6.90BAR
GH-008	0.750inch	19.05mm	0.175inch	4.45mm	1.125inch	28.58mm	90PSI	6.21BAR
GH-009	0.875inch	22.23mm	0.180inch	4.57mm	1.260inch	32.00mm	65PSI	4.48BAR
GH-010	1.000inch	25.40mm	0.190inch	4.83mm	1.405inch	35.69mm	60PSI	4.14BAR

If you need customized / special sizes, please click here to send an inquire to us. We will respond you in 24 hours.
